ADR233B
Fault Parameters
Data Attribute
Dataset
FLTGGIO35$MX$AnIn1$mag$f dchg
FLTGGIO35$MX$AnIn2$mag$f dchg
FLTGGIO35$MX$AnIn3$mag$f dchg
FLTGGIO35$MX$AnIn4$mag$f dchg
FLTGGIO35$MX$AnIn5$mag$f dchg
FLTGGIO35$MX$AnIn6$mag$f dchg
FLTGGIO35$MX$AnIn7$mag$f dchg
FLTGGIO35$MX$AnIn8$mag$f dchg
FLTGGIO35$MX$AnIn9$mag$f dchg
LED reset
Data Attribute
Dataset
LLN0$CO$LEDRs$Oper$ctlVal
LLN0$ST$LEDRs$stVal dchg
W1 CB 1-2 Binary Status Input 1-2
Data Attribute
Dataset
W1CBGGIO14$ST$Ind1$stVal dchg
W1CBGGIO14$ST$Ind2$stVal dchg
W2 CB 1-2 Binary Status Input 1-2
Data Attribute
Dataset
W2CBGGIO15$ST$Ind1$stVal dchg
W2CBGGIO15$ST$Ind2$stVal dchg
W1CB Circuit Breaker, T1 CB NO, T2 CB NC, Trip CB Open, Close CB Close
Data Attribute
Dataset
CBCSWI1$ST$Loc$stVal dchg
CBCSWI1$ST$OpCntRs$stVal dchg
CBCSWI1$ST$Pos$stVal dchg
W2CB Circuit Breaker, T1 CB NO, T2 CB NC, Trip CB Open, Close CB Close
Data Attribute
Dataset
CBCSWI2$ST$Loc$stVal dchg
CBCSWI2$ST$OpCntRs$stVal dchg
CBCSWI2$ST$Pos$stVal dchg
Group Change Control 1-4
Data Attribute Dataset
GRPGGIO36$CO$SPCSO1$Oper$ctlVal
