ADR233B
Figure 2: Front Panel details of ADR233B-M0
Sr. No. Legend Function
1.
L1
Programmable Dual Colour LED
Default Assignment: GREEN LED – indicates Relay Enabled.
Default Assignment: RED LED – indicates Relay Error.
2.
L2 Programmable Dual Colour LED
3.
L3 Programmable Dual Colour LED
4.
L4 Programmable Dual Colour LED
5.
L5 Programmable Dual Colour LED
6.
L6 Programmable Dual Colour LED
7.
L7 Programmable Dual Colour LED
8.
L8 Programmable Dual Colour LED
9.
L9 Programmable Dual Colour LED
10.
L10 Programmable Dual Colour LED
11.
L11 Programmable Dual Colour LED
12.
L12 Programmable Dual Colour LED
13.
L13 Programmable Dual Colour LED
14.
L14 Programmable Dual Colour LED
15.
L15 Programmable Dual Colour LED
16.
L16 Programmable Dual Colour LED
17.
LCD
Display
To observe settings and parameters of the relay.
