ADR233B
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 26 of 479
1 INTRODUCTION AND SPECIFICATIONS
1.1 Overview
ADR233B ADITYA series relay has been Designed and produced by ASHIDA. It is Economical
and reliable Multifunction Transformer Protection Relay. Its construction is simple and compact.
It provides integrated protection, Control and Monitoring functions for AC Transformer.
The ADR233B relay available in three versions: Basic, Enhanced and Modular versions.
1.2 Features
Key Protection & Control Functions:
• Four Independent Settings Groups.
• Two winding Phase Differential protection (87).
• Low / High Impedance Restricted Earth fault protection (64-REF).
• Non Directional Phase & Ground Over current Protection (50/50N/51/51N).
• Three Independent Stages of Non Directional Phase Over Current Function (50/51).
• Three Stages of Non Directional Internally Derived (3I0>) and Externally Measured (IE>)
Ground over current protection (50N/51N).
• Three independent Stages of Positive / Negative Sequence Over current Protection (46).
• 10 no’s of International standard (IEC, IEEE, UK & US) Inverse Definite Minimum Time
(IDMT) selectable Curves are available for Over Current Protection.
• Harmonic Blocking & Unblocking feature.
• Under and Over Voltage Protections (27/59).
• Six independent stages of V/Hz Protection (24).
• Breaker Failure detection (50BF).
• Thermal overload function (49).
• Trip circuit supervision function (TCS).
• SOTF Function (achieved by using Group Changeover facility through AProLogic).
• Programmable Inputs & Outputs.
• CB Close / Trip from HMI
• Programmable & Target LEDs for indication with dual colours (8 nos. for Basic / 16 nos. for
Enhance & Modular).
• Self Supervision of relay.
• Metering function.
• Disturbance Recording (10 nos.).
• Event Recording (512 nos.).
