ADR233B
W1 Phase OC
IP>1
1.00 A
0.05 – 4.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 can be set.
The setting range is from 0.05 to 4.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 TMS
0.10
Range 0.01 – 1.5
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 TMS can be set.
The setting range is from x0.01 to x1.5 in step of 0.01
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 D/O Char can be set i.e. Disabled /
DT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
W1 Phase OC
t IP>1 D/O Delay
0.01 s
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIP>1 D/O Delay can be set.
The setting range is from 0 to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 2H BLK can be set. i.e. Disabled /
Enabled.
Note: If Disabled the IP>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
If Enabled
