Ashida ADR233B - Page 330

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 330 of 479
ADR233B
W1 Phase OC
IP>1
1.00 A
0.05 – 4.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 can be set.
The setting range is from 0.05 to 4.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 Time Dial
1.00s
Range 0.01 – 100
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 Time Dial can be set.
The setting range is from 0.01 to 100 in steps of 0.01
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 D/O Char can be set i.e. Disabled /
DT / IDMT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
W1 Phase OC
t IP>1 D/O Delay
0.01 S
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIP>1 D/O Delay can be set.
The setting range is from 0s to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
IF IDMT
W1 Phase OC
IP>1 D/O TMS
1.000
Range 0.025 – 1.2
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 D/O TMS can be set.
The setting range is from 0.025 to 1.2 in step of 0.001
Press the Minus / Down arrow key (- /) to move to the next
option.
