Ashida ADR233B - Page 360

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 360 of 479
ADR233B
option.
W1 Sequence OC
Seq.I>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 2H BLK can be set i.e. Disabled
/ Enabled.
Note: If Disabled the Seq.I>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF Enabled
W1 Sequence OC
Seq.I>1 2H Thresh
5 %
Range 5 – 70%
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 2H Thresh can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1 UB2H
10.0 A
4.0 – 32.0 xIn
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 UB2H can be set.
The setting range is from 4.0 to 32.0 xIn in step of 0.1 xIn.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

