ADR233B
Ref ID : ADR233B/IM/I&P
Rev No. : 05
Page No. : 46 of 479
Figure 3: Inserting relay in to the panel cut-out
After inserting the Relay in the Panel using the Fitting clamps, M5 x 10 Screws are used to
fasten the relay to the Panel.
Figure 4: Fastening Relay to the panel
Caution: All screws of fitting clamps should be properly tightened. Always use
M5x10 screws for fitting the clamps.
The Relay after fastening to the Panel with M6 X 15 Screws is shown below.
