Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
267
of 820
4
9 … 4 Configuration setting of the combined measured values (if bit 1 = 0)
x bits revolutions + (32 - x) bits angle:
Value:
0: 32 bits angle
1: 1 bit revolutions + 31 bits angle
2: 2 bits revolutions + 30 bits angle
3: 3 bits revolutions + 29 bits angle
4: 4 bits revolutions + 28 bits angle
5: 5 bits revolutions + 27 bits angle
6: 6 bits revolutions + 26 bits angle
7: 7 bits revolutions + 25 bits angle
8: 8 bits revolutions + 24 bits angle
9: 9 bits revolutions + 23 bits angle
10: 10 bits revolutions + 22 bits angle
11: 11 bits revolutions + 21 bits angle
12: 12 bits revolutions + 20 bits angle
13: 13 bits revolutions + 19 bits angle
14: 14 bits revolutions + 18 bits angle
15: 15 bits revolutions + 17 bits angle
16: 16 bits revolutions + 16 bits angle
17: 17 bits revolutions + 15 bits angle
18: 18 bits revolutions + 14 bits angle
19: 19 bits revolutions + 13 bits angle
20: 20 bits revolutions + 12 bits angle
21: 21 bits revolutions + 11 bits angle
22: 22 bits revolutions + 10 bits angle
23: 23 bits revolutions + 9 bits angle
24: 24 bits revolutions + 8 bits angle
25: 25 bits revolutions + 7 bits angle
26: 26 bits revolutions + 6 bits angle
27: 27 bits revolutions + 5 bits angle
28: 28 bits revolutions + 4 bits angle
29: 29 bits revolutions + 3 bits angle
30: 30 bits revolutions + 2 bits angle
31: 31 bits revolutions + 1 bit angle
32: 32 bits revolutions
10 … 15 Reserved
19 … 16 Source for DS402 touch probe 1 (TP1)
(Z124.31– / Z124.32–, object 60BA / 60BB)
Value:
0: Encoder 1 trigger digital input TP1
1: Encoder 1 trigger digital input TP2
2: Encoder 1 trigger zero pulse
3: … 15: Reserved
Bit Meaning
