Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
266
of 820
4.4
124.16 Encoder 1 trigger zero pulse neg. edge angle
Angle Encoder 1 with triggering of measurement through falling edge of Zero Pulse of En-
coder 1.
124.30 DS402 mode
Settings for Z124.31– to Z124.34–.
Source and division of revolutions and angle.
NOTE!
for the DS402 touch probe 1 and 2 must not set the same source
Bit Meaning
0 1: Switch on DS402 touch probe 
Start calculation of the combined measured values Z124.31– to
Z124.34– and if necessary Z179.16– to Z179.19–.
The respective source is selected in bits 16 … 23.
Configuration/scaling of the combined measured values see bits 2 ... 1.
Attention:
The respective channel in Z124.1– Configuration mode must be activated!
0: Switch off
2 ... 1 Configuration/scaling of the combined measured values Z124.31– to
Z124.34–:
00: Configuration corresponding to bits 4 … 9
01: Calculation with Factor Group (Z179.2– to Z179.9–)
1)
10: Modulo actual position value
2)
11: Reserved
3 Reserved
