Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
268
of 820
4.4
1
) Z131.9– bit 14 Factor Group must be activated
2
) Z121.1– bit 4 modulo actual position value must be activated
124.31 DS402 touch probe 1 pos. value
DS402 touch probe object 0x60BA
The source is selected in Z124.30–.
The following scalings are possible:
m according to Z124.30– bits 9 ... 4 (Z124.30– bits 2 ... 1 = 00) or
m with the Factor Group weightings from Z179.2– to Z179.9– (Z124.30–
bit 2 ... 1 = 01) or
m position system of the modulo actual position value Z121.17– (Z124.30–
bit 2 ... 1 = 10)
124.32 DS402 touch probe 1 neg. value
DS402 touch probe object 0x60BB
The source is selected in Z124.30–.
The following scalings are possible:
m according to Z124.30– bits 9 ... 4 (Z124.30– bits 2 ... 1 = 00) or
m with the Factor Group weightings from Z179.2– to Z179.9– (Z124.30–
bit 2 ... 1 = 01) or
m position system of the modulo actual position value Z121.17– (Z124.30–
bit 2 ... 1 = 10)
23 … 20 Source for DS402 touch probe 2 (TP2)
(Z124.33– / Z124.34–, object 60BC / 60BD)
Value:
0: Encoder 1 trigger digital input TP1
1: Encoder 1 trigger digital input TP2
2: Encoder 1 trigger zero pulse
3: … 15: Reserved
31 … 24 Reserved
Bit Meaning
