Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
278
of 820
4.4
150.25 Derivative time PID controller 2
Derivative time (Td) of the PID controller.
150.26 PT
1
time constant PID controller 2
Time constant of the PT
1
filter in the D leg of the PID controller. If the value „0“ is specified,
the signal will be transmitted unfiltrated.
150.27 Output upper limit PID controller 2
Upper limit of the PID controller output.
If the output is limited with this limit, it will be signalized in Z150.18– bit 4.
150.28 Output lower limit PID controller 2
Lower limit of the PID controller output.
If the output is limited with this limit, it will be signalized in Z150.18– bit 4.
150.29 Set value PID controller 2
Value of the set value of the PID controller.
The source of this set value can be selected in Z150.20– „Source number set value PID
controller 2“.
If the source is not selected (Z150.20– = 0) the set value can be written via fieldbus or
an analogous input.
NOTE!
If the upper limit is greater than the maximum value of the linked target parameter,
then the output is limited at writing on the target parameter to the maximum value of
the linked target parameter if necessary. This will be signalized in
Z150.18– bit 8.
NOTE!
If the lower limit is less than the minimum value of the linked target parameter, then
the output is limited at writing on the target parameter to the minimum value of the
linked target parameter if necessary. This will be signalized in
Z150.18– bit 8.
