Management
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
388
of 820
4.5
100.3 Error Information
Parameter displays the errors and warnings.
The parameter is an array with 20 entries. Each entry contents the error number as well
as the additional information as e.g. the time of the occurrence and the time of reset (rel
-
ative time since switch-on).
If errors are reset then these are shifted to the end of the array. By reading out the array
completely, it is possible to access error messages prior to the last reset.
The number of the relevant entries (i.e. the not yet acknowledged messages) is displayed
in parameter
Z100.2– Error Count.
Each array entry is a structure with the following data elements:
100.4 Error Reaction
Parameter for adjustment of the error response for the different errors.
The parameter is defined as a structure of arrays. The number of elements in the upper-
level structure and the number of array elements is equivalent to the number of error
groups and the number of errors in the group (see
ZError descriptions– from page 747).
Each array element is a structure with the following data elements:
The following values are possible for the error response:
Name Meaning
RC Error code (see ZError descriptions– from page 747)
FB Type Functional block type
FB Instance Instance number of the FB
Set Time Timestamp of when the error was reported
Reset Time Timestamp of when the error was reset
Error Response Error response code (see Z100.4– table)
Info1 Additional error information1 (depends on the error message).
Info2 Additional error information2 (depends on the error message).
Name Meaning
RC Error code
Error Response Error response code
Code Error reaction
-5 SS1 stop
-4 Controlled stop
-3 Return motion
-2 No error message
