118.17 Remaining distance
This parameter shows the remainder of the target distance to be traveled to the destina-
tion during a positioning procedure.
118.18 Positioning timeout
Positioning time monitoring is activated through Z118.2– Mode Bit 14 = 1.
Monitoring can be used to check whether the destination is reached accurately or fast
enough through the actual value.
As soon as the set value entry is completed through positioning, a timer will be started.
The position actual value must be within the positioning window (
Z121.5–) at least once
prior to expiration of the monitoring time. If this is the case, Bit 7 will be set in the Z118.1–
status.
Otherwise, a timeout error will be generated.
118.19 Positioning records
The parameter consists of 16 positioning records. The positioning records 1 to 16 cannot
be described cyclically! Each positioning set consists of the following elements:
NOTE!
The remaining distance is not calculated at set value setting ("Set of setpoints"). The
remaining distance calculation is active not until the finally positioning via data set
setting.
NOTE!
This type of monitoring must not be mistaken for positioning window / time monitor-
ing.
Positioning window / time monitoring requires a stable actual value within the posi-
tioning window and controls the Bit "Position Target Reached".
Index Element Description of elements
0 Target position Refer to Z118.9– Positioning Target Position
1 Target mode Refer to Z118.10– Positioning Target mode
2 Positioning speed Refer to Z118.11– Positioning Speed
3 Positioning acceleration Refer to Z118.12– Positioning Acceleration
4 Positioning deceleration Refer to Z118.13– Positioning Deceleration
