Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
703
of 820
4
101.8 Channel 5 source parameter Id
See Z101.3–
101.9 Channel 6 source parameter Id
See Z101.3–
101.10 Channel 7 source parameter Id
See Z101.3–
101.11 Trigger source parameter Id
Parameter ID for trigger events that are freely programmable:
The value of RSP Trigger Source Pxxx is compared with the trigger comparison value
(
Z101.15–) and a trigger is activated when the trigger condition (Z101.14–) is met.
101.12 Trigger mode
Setting the corresponding bit will trigger the ring buffer for the associated event.
NOTE!
Trigger data changes must always be made in Status 0 (Recording Stop) only.
Bit-no. Value Trigger event
0 0x0001 Reserved
1 0x0002 Reserved
2 0x0004 Freely programmable trigger event
3 0x0008 Reserved
4 0x0010 Trigger on positive edge
5 0x0020 Trigger on negative edge
15 ... 6 Reserved
