Error descriptions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
750
of 820
5.5
212 Parameterization allows exceeding of
the maximum speed of the motor
The set value for the Z107.26– max. speed mech. can be exceeded
because of the existing parameter settings. If Z107.26– = 0 rpm the
check of the parameter does not proceed.
m Cause:
a) Parameter Z107.26– max. speed mech. is set wrong.
b) The ramp function generator is used in operating modes -3 and
2. There
Z110.13– Standardization Output Value is used for stan-
dardization. If Z110.13– is greater than Z107.26– the error is set
at drive enabling. If the error is ignored the speed set value
already can exceed the maximum speed mechanical.
c) The Overspeed Limits in parameter Z6.5– and Z6.6– are set
too large. The check of the actual speed protects the motor insuf-
ficiently.
n Remedy:
a) Enter a valid value in Z107.26–.
b) Adjust the standardization for the ramp function generator
(
Z110.13– Z107.26–)
c) Adjust the Overspeed Limits (|Limit| Z107.26–)
No response
213 Position difference greater than thresh-
old in gantry mode
The difference of the position in gantry mode is greater than the vari-
able threshold.
No response
214 Gantry mode: current difference
greater than threshold
In gantry mode the current difference is greater than the variable
threshold
No response
215 Controller fan not working The fan of the controller board is switched on but the controller gets
no feedback from the tachometer. Either the fan is not working or the
tachometer signal is broken.
No response
216 Power unit monitoring responded;
PWM frequency reduced
Power unit monitoring (temperature model) responded; PWM fre-
quency reduced (halved)
No response
217 Dual-Use: electrical frequency to high This device is a dual-use-device and the electrical frequency is to
high. The maximum value is 600 Hz Output frequency.
Pulse block
218 Peak current of power unit is reduced The power unit peak current is reduced to protect the unit from dam-
age
No response
219 Warning motor 12t overload Warning: motor i²t overload No response
220 Power unit overload during operation
mode voltage setting
Power unit overload. In the operation mode, voltage setting, the cur-
rent cannot be limited. The reaction to the overload is impulse inhibit
Pulse block
221 Exceedance warning threshold of real
power
Only für single Phase Units (BM3300) with DC link supply from
mains. Here the real power has to be limited, otherwise the DC link
will not get enough energy from mains.
No response
222 Exceedance error threshold of real
power limitation
Only for single Phase Units (Bm3300) with DC link supply from
mains. Here the real power has to be limited, otherwise the DC link
will not get enough energy from mains.
Pulse block
400 Amplitude of the encoder signal too
small
Encoder monitoring has detected an amplitude that is too small at
Sin
2
+cos
2
monitoring. Either the encoder has a problem or the mon-
itoring threshold is set too great.
Pulse block
401 Amplitude of the encoder signal too
great
Encoder monitoring has detected an amplitude that is too great at
Sin
2
+cos
2
.
Pulse block
402 Error while initializing the position
through Sin/Cos signals.
Error while initializing the position (the analogous signals do not
agree with the position which was digital read out).
Pulse block
403 Encoder monitoring: Overspeed due to
sector error
Sector error occurred while the encoder evaluation, which means
the calculated speed is too great
Pulse block
404 Signal monitoring at square-wave
incremental encoder
The signal monitoring of a square-wave incremental encoder has
recognized an error.
Pulse block
405 CRC error in received data CRC error in received data from EnDat
®
2.1 or SSI Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
