Baumuller b maXX BM3000 User Manual

Error messages and troubleshooting
Parameter manual b maXX BM3000
Document no.: 5.12001.07
749
of 820
5
170 Firmware for communication processor
could not be downloaded
Firmware for communication processor could not be downloaded
The error is messaged, if the firmware could not be downloaded to
the communication processor at the boot sequence.
Either both firmware files (actual and fallback) of the communication
firmware are faulty or nonexistent (error info1 = 0) or an error has
occurred at the file download to the communication processor (error
info1 = 1).
Pulse block
172 Lead drive error Error within communication between two drives. The coupled drive
reported an error. The receiver drive reports error 172, if a new error
reaction is invoked and the error reaction is none of "no reaction" nor
"no error, no reaction". Then the drive reacts with the received error
reaction. The entry in the error reaction table is not used, since the
received error reaction will be used.
No response
173 PLC Translation error Error when translating the PLC project No response
174 PLC runtime error PLC runtime error No response
175 Application error 1 Freely definable application error 1 No response
176 Application error 2 Freely definable application error 2 No response
177 Application error 3 Freely definable application error 3 No response
178 Application error 4 Freely definable application error 4 No response
179 Application error 5 Freely definable application error 5 No response
201 Exceeded limit pos. speed control devi-
ation
Speed deviation > Maximum positive speed difference (parameter
Z6.7–)
No response
202 Exceeded limit neg. speed control devi-
ation
Speed deviation < Maximum negative speed difference (parameter
Z6.8–)
No response
203 Positive overspeed limit exceeded x2 speed actual value > Positive overspeed limit (parameter Z6.5–) Pulse block
204 Negative overspeed limit exceeded x2 speed actual value < Neg. overspeed limit (parameter Z6.6–) Pulse block
205 Motor i2t overload The current i2t value (Z6.28–) has exceeded the limit value for the
i2t model (Z6.29–).
Pulse block
206 LT monitoring approached; max. torque
current was limited
I*t monitoring of power unit is operating; the maximum available
torque current is limited.
Details see ZOverload monitoring of the power unit– ab Seite 723.
No response
207 Exceeded position error limit 1 Error occurs when position error limit 1 is exceeded. Pulse block
208 Exceeded position error limit 2 The error occurs when position error limit 2 is exceeded Pulse block
209 Blockage monitoring: Blocking time 1
exceeded
The drive is blocked longer than the set Blockade Time Limit 1
(Parameter 6.21).
The warning will be deleted automatically if the condition for blocking
is no longer met.
No response
210 Blockage monitoring: Blocking time 2
exceeded
The drive is blocked longer than the set Blockade Time Limit 2
(Parameter 6.22).
Pulse block
211 Error While Monitoring the Field Angle Error while monitoring the field angle is greater than 45° Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
