Error descriptions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
770
of 820
5.5
2743 No cam data available in internal buffer The intermediate buffer doesn't include valid polynomial curve data.
Presumably the required data weren't able to be added in time. It is
recommended to reduce the speed of the master or to increase the
scope of the individual curve segments.
m Consequence:
The processing of the polynomial curves must be interrupted.
Pulse block
2744 Master axis in motion during synchroni-
zation
In the Z122.2– mode of the "Coupled operation" was set that the
master axis must stop during the synchronization phase. However a
position change was determined at the master axis position.
m Consequence:
Depending on the error reaction. If there is no reaction parameter-
ized, the drive processes the synchronization of the polynomial
curves anyway. However, the polynomial curve and the synchroni
-
zation movement overlap.
No response
2745 Invalid start position of the master axis A valid starting position of the master axis in the parameter Z122.8–
and Z122.9– was not defined.
m Cause
Based on the starting position the current master axis position
Z122.3– and Z122.4– are not within the linking of the active
curve.
Pulse block
2746 File handler busy Although the previous transmission was not completed yet a polyno-
mial curve was transmitted.
No response
2747 Transmitted file includes unknown
curve type
The transmitted curve contains an unknown curve type.
m Consequence:
The transmission is interrupted and the file is canceled.
No response
2748 An active curve could not be deleted It's not permitted to overwrite the polynomial curve completely
during processing. However, the reload by using a changed curve
segment would be possible.
m Consequence:
The previous curve is continued to be processed.
No response
2749 Cam file version is unknown The controller firmware doesn't know the version of the transmitted
cam file.
m Consequence:
The cam file is rejected.
No response
2750 To many revolutions per segment
defined
One of the transmitted curve segments was defined for more than
65535 master or slave revolutions.
m Consequence:
The cam file is rejected.
No response
2800 No identification in the DPRAM Header No identification found in the DPRAM Header (DEADBEEF) No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
