Error messages and troubleshooting
Parameter manual b maXX BM3000
Document no.: 5.12001.07
769
of 820
5
2702 Error in the configuration of the return
motion
General error in the configuration of the return motion detected by
the test function.
Cause:
m The motorized operation at supply failure is not permitted
(
Z130.10– Supply mode bit 1 = 0)
Pulse block
2703 Return motion target not reached The return motion positioning did not reach the target. This is
described in
Z148.2– Status bits 4, 8-11:
n Inhibit/interrupt by command in Z148.1– mode
n Interrupt due to hardware-ended pulse inhibit
n Interrupt due to higher-ordered error reaction
n Interrupt due to return-motion-own position error monitoring
Pulse block
2720 Cam generator - no input parameter
was selected
Selection of processing mode "parameter-controlled processing"
No input parameter was selected.
No response
2721 Cam generator - no reference parame-
ter was selected
Selection of relative mode, but no reference parameter was
selected.
No response
2722 Cam generator - no output parameter
was selected
No target parameter was selected. No response
2723 Cam generator - the output value was
limited
The output value of the cam is greater than the maximum value of
the target parameter or the output value is lower than the minimum
value of the target parameter.
Pulse block
2724 Cam generator - in the RAM no valid
cam was found
An attempt was made to start the cam generator, although there was
no applicable cam in the RAM
No response
2725 Cam generator - an error occurred
while loading the cam
An attempt to load a cam into the device failed.
m Possible causes:
n Cam has more than 1024 supporting points
n An attempt was made to load a cam, although another cam was
processing yet
n An attempt was made to load a wrong file. Only files with exten-
sion *.kbin can be loaded.
No response
2726 Cam generator - the active cam cannot
be used in this mode
In the "parameter-controlled processing" mode the cyclical process-
ing is selected. The count of supporting points must accord to power
2. This is not the case at the active cam (e.g. count of supporting
points is 256, 512 or 1024)
No response
2740 No polynomial curve data available It was tried to release the drive in the operation mode "Coupled
operation" but there is no polynomial curve data in the controller.
m Consequence:
The operation in the coupled operation isn't possible. Behavior
accordant to set error reaction.
Pulse block
2741 Invalid segment number detected At the polynomial curve generator an invalid segment number was
transferred for which there is no segment existent.
This error can occur at the transmission of the curve segments or at
a chain change.
m Consequence:
The transmitted curve segments are rejected.
Pulse block
2742 No valid start segment defined The start segment defined in the parameter Z122.7– isn't in the
polynomial curve.
m Consequence:
The polynomial curve generator cannot be activated.
Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
