Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
775
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
29.12 Coefficient a3 FLOAT -1000000 1000000 0.0 1:1 X
29.13 Coefficient a4 FLOAT -1000000 1000000 0.0 1:1 X
29.14 Coefficient a5 FLOAT -1000000 1000000 0.0 1:1 X
29.15 Coefficient a6 FLOAT -1000000 1000000 0.0 1:1 X
29.16 Coefficient a7 FLOAT -1000000 1000000 0.0 1:1 X
29.17 Coefficient b1 FLOAT -1000000 1000000 0.0 1:1 X
29.18 Coefficient b2 FLOAT -1000000 1000000 0.0 1:1 X
29.19 Coefficient b3 FLOAT -1000000 1000000 0.0 1:1 X
29.20 Coefficient b4 FLOAT -1000000 1000000 0.0 1:1 X
29.21 Coefficient b5 FLOAT -1000000 1000000 0.0 1:1 X
29.22 Coefficient b6 FLOAT -1000000 1000000 0.0 1:1 X
29.23 Coefficient b7 FLOAT -1000000 1000000 0.0 1:1 X
29.29 Filter cycle time FLOAT 62.5 1000 250 µs 1:1 X
47.1 Isq set value FLOAT -10000 10000 0 A 1:1 X
47.2 Isd set value FLOAT -10000 10000 0 A 1:1 X
47.3 Isq actual value FLOAT -10000 10000 0.0 A 1:1 X
47.4 Isd actual value FLOAT -10000 10000 0.0 A 1:1 X
47.5 Isq act value filtered FLOAT -10000 10000 0.0 A 1:1 X
47.6 Isd act value filtered FLOAT 110000 10000 0.0 A 1:1 X
47.7 P-Gain 4kHz Iq FLOAT 0.0 1.0e+04 10.0 V/A 1:1 X X
47.8 Integral action time Iq FLOAT 0.0 1.0e+04 5.0 ms 1:1 X X
47.9 P-Gain 4kHz Id FLOAT 0.0 1.0e+04 10.0 V/A 1:1 X X
47.10 Integral action time Id FLOAT 0.0 1.0e+04 5.0 ms 1:1 X X
47.20 Usq set value FLOAT -440 440 0.0 V 1:1 X
47.21 Usd set value FLOAT -440 440 0.0 V 1:1 X
47.22 Integral term Usq FLOAT -440 440 0.0 V 1:1 X
47.23 Integral term Usd FLOAT -440 440 0.0 V 1:1 X
47.24 Usq control output FLOAT -440 440 0 V 1:1 X
47.25 Usd control output FLOAT -440 440 0 V 1:1 X
47.26 Back-EMF feed forward FLOAT -440 440 0.0 V 1:1 X
47.27 U Alpha set value FLOAT -440 440 0.0 V 1:1 X
47.28 U Beta set value FLOAT -440 440 0.0 V 1:1 X
47.29 Control value U FLOAT 0.0 1.0 5.0e-01 1:1 X
47.30 Control value V FLOAT 0.0 1.0 5.0e-01 1:1 X
47.31 Control value W FLOAT 0.0 1.0 5.0e-01 1:1 X
47.32 Iu actual value FLOAT -10000 10000 0.0 A 1:1.414 X
47.33 Iv actual value FLOAT -10000 10000 0.0 A 1:1.414 X
47.34 Iw actual value FLOAT -10000 10000 0.0 A 1:1.414 X
47.40 PWM MSVM threshold UINT 0 100 100 % 1:1 X
47.41 Ualpha after PWM FLOAT -440 440 0 V 1:1 X
47.42 Ubeta after PWM FLOAT -440 440 0 V 1:1 X
47.43 Uq after PWM FLOAT -440 440 0 V 1:1 X
47.44 Ud after PWM FLOAT -440 440 0 V 1:1 X
