Baumuller b maXX BM3000 User Manual

Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
777
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
101.1 Status INT 0 5 0 1:1 X
101.2 Command INT 0 7 0 1:1 X
101.3 Channel 0 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.4 Channel 1 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.5 Channel 2 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.6 Channel 3 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.7 Channel 4 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.8 Channel 5 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.9 Channel 6 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.10. Channel 7 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.11 Trigger source parameter id UDINT 0 4294967295 0 ID 1:1 X
101.12 Trigger mode UDINT 0 0x00000077 0 1:1 X
101.13 Trigger axis mask UINT 0x1 0x3 0x1 1:1 X
101.14 Trigger condition UDINT 0 0x0000003F 0 1:1 X
101.15 Trigger compare value FLOAT -5.000000e+9 5.000000e+9 0.000000e+00 1:1 X
101.16 Trigger compare mask UDINT 0 0xFFFFFFFF 0 1:1 X
101.17 Trigger cause UINT 0 1999 0 1:1 X
101.18 Sample time FLOAT 0.0000625 100 0.001 s 1:1 X
101.19 After-run time FLOAT 3.000000e-01 3.000000e+06 1.000000e+00 s 1:1 X
101.20 Recording time FLOAT 1.000000e+01 3.000000e+06 1.000000e+01 s 1:1 X
101.21 Buffer size UDINT 10000 504000 10000 DW 1:1 X
101.22 Measure time FLOAT 0 10000 0 µs 1:1 X
101.23 Scope buffer FLOAT -1.000000e+37 1.000000e+37 0.000000e+00 1:1 X
101.24 Task number UINT 1 2 2 1:1 X
102.1 Firmware number UDINT 0 0xFFFFFFFF 0 1:1 X
102.2 Firmware version UDINT 0 0xFFFFFFFF 0 1:1 X
102.3 Firmware type UDINT 0 5 0 1:1 X
102.4 Firmware build number UDINT 0 0xFFFFFFFF 0 1:1 X
102.5 Firmware name STRING 1:1 X
102.6 Firmware version information STRING 1:1 X
102.7 Firmware time stamp STRING 1:1 X
102.8 Bootloader0 version STRING 1:1 X
102.9 Bootloader1 version STRING 1:1 X
102.10 Fpga Id UDINT 0 0xFFFFFFFF 0 1:1 X
102.11 Bootloader flags UDINT 0 0xFFFFFFFF 0 1:1 X
102.13 Expected system Fpga Id UDINT 0 0xFFFFFFFF 0 1:1 X
102.14 FPGA version UDINT 0 0xFFFFFFFF 0 1:1 X
