Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
778
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
102.15 FPGA firmware number UDINT 0 0xFFFFFFFF 0 1:1 X
102.18 Fieldbus controller firmware
number
UDINT 0 0xFFFFFFFF 0 1:1 X
102.19 Fieldbus controller firmware
version
UDINT 0 0xFFFFFFFF 0 1:1 X
102.20 Fieldbus controller firmware
version time stamp
STRING 1:1 X
102.21 Fieldbus controller firmware
type
UDINT 0 0xFFFFFFFF 0 1:1 X
102.22 Fieldbus controller firmware
build number
UDINT 0 0xFFFFFFFF 0 1:1 X
102.23 Board data command UINT 0 0x1000 0 1:1
102.24 Board data status UDINT 0 0xFFFF 0 1:1 X
102.25 Hardware board identification STRING 1:1
102.26 Circuit board assembly STRING 1:1
102.28 Hardware date STRING 1:1
102.30 Controller serial number UDINT 0 0xFFFFFFFF 0 1:1
102.31 Controller article number UDINT 0 0xFFFFFFFF 0 1:1
102.32 Device serial number UDINT 0 0xFFFFFFFF 0 1:1
102.33 Device article number UDINT 0 0xFFFFFFFF 0 1:1
102.35 Device type Code STRING 1:1
103.1 FPGA data DINT 0 0 0 1:1 X
104.1 Command UDINT 0 4 0 1:1 X
104.2 Status UDINT 0 41 0 1:1 X
104.3 Signal input 1 source Pxxx UDINT 0 0xFFFFFFFF 0 1:1 X
104.4 Signal input 2 source Pxxx UDINT 0 0xFFFFFFFF 0 1:1 X
104.5 Signal input 1 / 2 axis UINT 0 0x11 0 1:1 X
104.6 Signal out target-Pxxx UDINT 0 0xFFFFFFFF 0 ID 1:1 X
104.7 FFT mode UDINT 0 0xFFFF 0 1:1 X X
104.8 FFT info DINT 0 12 0 1:1
104.9 FFT length DINT 64 4096 4096 1:1 X
104.10 FFT windowing UINT 0 5 1 1:1 X
104.11 Average number setup DINT 0 20000 16 1:1 X
104.12 Signal out amplitude FLOAT -1e+9 1e+9 0 1:1 X
104.13 Signal output offset FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.14 Frequency for sinus genera-
tor
FLOAT 0 8000 0 Hz 1:1 X
104.15 Signal out FLOAT -1e+9 1e+9 0 1:1 X
104.16 Input signal 1 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.17 Input signal 2 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.18 Actual average DINT 0 20000 0 1:1 X
104.19 Max. frequency FLOAT 0.000000e+00 8000 2000 Hz 1:1 X
104.20 Frequency resolution FLOAT 0.000000e+00 62.5 9.765625e-01 Hz 1:1 X
104.21 FFT data FLOAT 0 0 0 1:1 X
