Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
780
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
106.46 Resolver set phase offset UINT 0 0xFFFF 20 µs 1:1 X
106.47 Resolver actual phase offset UINT 0 0xFFFF 0 µs 1:1 X
106.52 Resolver phase synchroniza-
tion
UINT 0 124 0 µs 1:1 X
106.60 SSI mode UDINT 0 0xFFFFFFFF 0x00004000 1:1 X
106.61 SSI status UDINT 0 0xFFFFFFFF 0 1:1 X
106.62 SSI bits angle UINT 0 31 12 1:1 X
106.63 SSI bits revolutions UINT 0 31 12 1:1 X
106.64 SSI angle UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.65 SSI revolutions UDINT 0 0xFFFFFFFF 0 1:1 X
106.70 Encoder excentricity angular
phase shift
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.71 Encoder excentricity angular
amplitude
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.72 State of encoder optimization DINT 0 0xFF 0 1:1 X
106.75 Maximal harmonic UINT 0 3 0 1:1 X
106.76 Amplitudes of the harmonics UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.77 Phases of the harmonics UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.81 DSL communication error
counter
UDINT 0 0xFFFFFFFF 0 1:1 X
107.1 Version UINT 0 0xFFFF 0 1:1 X
107.2 Motor type STRING 1:1 X
107.3 Article number UDINT 0 0xFFFFFFFF 0 1:1 X
107.4 Serial number UDINT 0 0xFFFFFFFF 0 1:1 X
107.5 Nominal operation mode UINT 0 0xFFFF 0 1:1 X
107.6 Nominal power FLOAT 0 655.35 5 kW 1:1 X
107.7 Nominal speed UINT 1 65535 3000 U/min 1:1 X
107.8 Nominal voltage FLOAT 0 6553.5 0 V 1:1 X
107.9 Nominal current FLOAT 0 6553.5 3.5 A 1:1 X
107.10 Standstill current FLOAT 0 6553.5 0 A 1:1 X
107.11 Standstill torque FLOAT 0 42949672.95 0 Nm 1:1 X
107.12 Power factor FLOAT 0 1.000 0.9 1:1 X
107.13 Nominal frequency FLOAT 0 6553.5 0 Hz 1:1 X
107.14 Magnetic current FLOAT 0 6553.5 0.01 A 1:1 X
107.15 Slip frequency cold FLOAT 0 655.35 2 Hz 1:1 X
107.16 Slip frequency warm FLOAT 0 655.35 3 Hz 1:1 X
107.17 Slip temperature cold UINT 0 655 0 Grad
C
1:1 X
107.18 Slip temperature warm UINT 0 655 100 Grad
C
1:1 X
107.19 Pole pairs UINT 1 65535 3 1:1 X
107.20 Ke factor FLOAT 0 6553.5 20 V/
1000U
/min
1:1 X
107.21 Max current FLOAT 0 6553.5 0 A 1:1 X
