Baumuller b maXX BM3000 User Manual

Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
784
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
116.17 Bit selection digital input 3 DWORD 0 0xFFFFFFFF 0 1:1 X
116.18 Set bit pattern for LOW state
digital input 3
DWORD 0 0xFFFFFFFF 0 1:1 X
116.19 Set bit pattern for HIGH state
digital input 3
DWORD 0 0xFFFFFFFF 0 1:1 X
116.20 Mode digital input 4 WORD 0 0xFFFF 0 1:1 X
116.22 Target number digital input 4 UDINT 0 0xFFFFFFFF 0 1:1 X
116.23 Bit selection digital input 4 DWORD 0 0xFFFFFFFF 0 1:1 X
116.24 Set bit pattern for LOW state
digital input 4
DWORD 0 0xFFFFFFFF 0 1:1 X
116.25 Set bit pattern for HIGH state
digital input 4
DWORD 0 0xFFFFFFFF 0 1:1 X
117.1 Status digital outputs DWORD 0 0xFFFFFFFF 0 1:1 X
117.2 Mode digital output 1 WORD 0 0xFFFF 0 1:1 X
117.4 Source number digital output
1
UDINT 0 0xFFFFFFFF 0 1:1 X
117.5 Bit selection digital output 1 DWORD 0 0xFFFFFFFF 0 1:1 X
117.6 Compare bit pattern digital
output 1
DWORD 0 0xFFFFFFFF 0 1:1 X
117.7 Mode digital output 2 WORD 0 0xFFFF 0 1:1 X
117.9 Source number digital output
2
UDINT 0 0xFFFFFFFF 0 1:1 X
117.10 Bit selection digital output 2 DWORD 0 0xFFFFFFFF 0 1:1 X
117.11 Compare bit pattern digital
output 2
DWORD 0 0xFFFFFFFF 0 1:1 X
117.22 Mode DWORD 0 0xFFFFFFFF 0 1:1 X X
117.23 Bit mask digital outputs WORD 0 0xF 0 1:1 X
118.1 Status DWORD 0x0 0xFFFFFFFF 0x0 1:1 X
118.2 Mode DWORD 0x0 0xFFFFFFFF 0x0 1:1 X X
118.3 Output position set value UDINT 0x0 0xFFFFFFFF 0x0 Inc 1:1 X
118.4 Output speed set value DINT -65535 65535 0 Inc/ms 1:1 X
118.5 Output acceleration set value DINT -65535 65535 0 Inc/
ms²
100:1 X
118.6 Record number actual UINT 0 16 0 1:1 X X
118.7 Clip environment 1 UDINT 0x1 0xFFFFFFFF 0x00010000 Inc 1:1 X
118.8 Clip environment 2 UDINT 0x1 0xFFFFFFFF 0x00010000 Inc 1:1 X
118.9 Target position UDINT 0x0 0xFFFFFFFF 0x0 Inc 1:1 X X
118.10 Target mode INT -2 17 0 1:1 X X
118.11 Speed UDINT 1 65535 100 Inc/ms 1:1 X X
118.12 Acceleration UDINT 7 65535 200 Inc/
ms²
100:1 X X
118.13 Deceleration UDINT 7 65535 200 Inc/
ms²
100:1 X X
118.14 Jerk UDINT 7 65535 25 Inc/
ms³
100:1 X X
118.15 Smoothing time UINT 0 8191 0 ms 1:1 X X
