Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
789
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
124.33 DS402 touch probe 2 pos.
value
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
124.34 DS402 touch probe 2 neg.
value
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
125.1 Visu Channel 1 source para-
meter id
UDINT 0 4294967295 0 1:1 X
125.2 Visu Channel 2 source para-
meter id
UDINT 0 4294967295 0 1:1 X
125.3 Visu command UINT 0 1 0 1:1 X
125.4 Visu status UINT 0 1 0 1:1 X
125.7 Visu task no UINT 0 3 3 1:1 X
125.8 General scaling FLOAT -5000000000 5000000000 1.000000e+00 Unit/V 1:1 X
125.9 Force scaling FLOAT 0 2147483648 1.000000e+00 N/V 1:1 X
125.10 Current scaling FLOAT -5000000000 5000000000 1.000000e+00 A/V 1:1 X
125.11 Voltage scaling FLOAT -5000000000 5000000000 1.0 V/V 1:1 X
125.12 Position scaling FLOAT -5000000000 5000000000 3.600000e+01 Unit/V 1:1 X
125.13 Speed scaling FLOAT -5000000000 5000000000 1.000000e+03 Unit/V 1:1 X
125.14 Acceleration scaling FLOAT -5000000000 5000000000 4 Unit/V 1:1 X
125.15 Torque scaling FLOAT -5000000000 5000000000 1 Nm/V 1:1 X
125.17 Test Signal amplitude FLOAT 0 5000000000 0 V 1:1
125.18 Correction gain channel 1 FLOAT 0 5000000 1.000 1:1 X
125.19 Correction gain channel 2 FLOAT 0 5000000 1.000 1:1 X
125.20 Offset channel 1 FLOAT -10.0 10.0 0 V 1:1 X
125.21 Offset channel 2 FLOAT -10.0 10.0 0 V 1:1 X
125.22 Test signal FLOAT -5000000000 5000000000 0 V 1:1
126.1 Parameter Int16_1 INT -32768 32767 0 1:1 X X
126.2 Parameter Int16_2 INT -32768 32767 0 1:1 X X
126.3 Parameter Int16_3 INT -32768 32767 0 1:1 X X
126.4 Parameter Int16_4 INT -32768 32767 0 1:1 X X
126.5 Parameter Int16_5 INT -32768 32767 0 1:1 X X
126.21 Parameter Uint16_1 UINT 0 0xFFFF 0 1:1 X X
126.22 Parameter Uint16_2 UINT 0 0xFFFF 0 1:1 X X
126.23 Parameter Uint16_3 UINT 0 0xFFFF 0 1:1 X X
126.24 Parameter Uint16_4 UINT 0 0xFFFF 0 1:1 X X
126.25 Parameter Uint16_5 UINT 0 0xFFFF 0 1:1 X X
126.41 Parameter Int32_1 DINT -2147483647 2147483647 0 1:1 X X
126.42 Parameter Int32_2 DINT -2147483647 2147483647 0 1:1 X X
126.43 Parameter Int32_3 DINT -2147483647 2147483647 0 1:1 X X
126.44 Parameter Int32_4 DINT -2147483647 2147483647 0 1:1 X X
126.45 Parameter Int32_5 DINT -2147483647 2147483647 0 1:1 X X
126.61 Parameter Uint32_1 UDINT 0 0xFFFFFFFF 0 1:1 X X
126.62 Parameter Uint32_2 UDINT 0 0xFFFFFFFF 0 1:1 X X
126.63 Parameter Uint32_3 UDINT 0 0xFFFFFFFF 0 1:1 X X
126.64 Parameter Uint32_4 UDINT 0 0xFFFFFFFF 0 1:1 X X
