Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
792
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
130.37 Udc threshold for mains fai-
lure
FLOAT 10 1000 450 V 1:1 X
130.38 Udc hysteresis for mains fai-
lure
FLOAT 10 500 50 V 1:1 X
130.39 Udc autodetect FLOAT 0 1000 0 V 1:1 X
130.41 Actual PWM frequency UINT 2 16 8 kHz 1:1 X
131.1 Mode WORD 0 0xFFFF 0 1:1
131.2 State WORD 0 0xFFFF 0 1:1
131.3 Producer list UDINT 0 0xFFFFFFFF 0 1:1 X
131.4 Consumer list UDINT 0 0xFFFFFFFF 0 1:1 X
131.5 Producer counter UDINT 0 0xFFFFFFFF 0 1:1
131.6 Consumer counter UDINT 0 0xFFFFFFFF 0 1:1
131.7 Last producer index UINT 0 0xFFFF 0 1:1
131.8 Last consumer index UINT 0 0xFFFF 0 1:1
131.9 Slave settings DWORD 0 0xFFFFFFFF 0 1:1 X
131.10 Slave info UDINT 0 0xFFFFFFFF 0 1:1 X
131.11 MAC address STRING 1:1
131.12 Base Ip address UDINT 0 0xFFFFFFFF 0xC0A80000 1:1 X
131.13 DIP switch settings UDINT 0 0xFFFFFFFF 0 1:1 X
131.14 Software IP address UDINT 0 0xFFFFFFFF 0 1:1 X
131.15 Actual IP address UDINT 0 0xFFFFFFFF 0 1:1 X
131.16 Gateway UDINT 0 0xFFFFFFFF 0 1:1 X
131.17 Subnet mask UDINT 0 0xFFFFFFFF 0xffff0000 1:1 X
131.18 Fieldbus cycle time UDINT 125000 8000000 1000000 ns 1:1 X
131.19 Slave error code UDINT 0 0xFFFFFFFF 0 1:1 X
131.20 Division ratio fieldbus task UINT 1 32 1 1:1 X
131.21 Configuration profile 1 DWORD 0 0xFFFFFFFF 0x0 1:1 X
131.22 Fieldbus type WORD 0 0xFFFF 0 1:1
131.23 Options DWORD 0 0xFFFFFFFF 0 1:1 X
131.24 Profinet device name UINT 0 0xFF 0 1:1 X
131.52 Error counter fieldbus actual
values
UDINT 0 0xFFFFFFFF 0 1:1 X
131.53 Error counter fieldbus set
values
UDINT 0 0xFFFFFFFF 0 1:1 X
131.55 Max error count fieldbus
actual values
UDINT 0 0xFFFFFFFF 2 1:1 X
131.56 Max error count fieldbus set
values
UDINT 0 0xFFFFFFFF 2 1:1 X
132.1 Mode DWORD 0 0xFFFFFFFF 0 1:1 X
132.2 Status DWORD 0 0xFFFFFFFF 0 1:1 X
132.3 Output FLOAT -5000000000 5000000000 0 1:1 X
132.4 Target number output UDINT 0 0xFFFFFFFF 0 1:1 X
132.10 Set value 1 FLOAT -5000000000 5000000000 0 1:1 X
132.11 Duration zone 1 UDINT 1 4294967295 1000 ms 1:1 X
