Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
794
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
136.6 Angle offset DINT 0x80000000 0x7FFFFFFF 0x0 Inc 1:1 X
136.7 Offset speed DINT 0x80000000 0x7FFFFFFF 0 Inc/ms 1:1 X
136.8 Output position set value UDINT 0x0 0xFFFFFFFF 0x0 Inc 1:1 X
136.9 Output speed set value DINT -65535 65535 0 Inc/ms 1:1 X
136.10 Output acceleration set value DINT -65535 65535 0 Inc/
ms²
100:1 X
136.11 Active interpolation interval UINT 125 32000 1000 µs 1:1 X
136.12 Output angle set value UDINT 0 0xFFFFFFFF 0x0 Inc 1:1 X
136.13 Smoothing position set value FLOAT 0 32 0 ms 1:1 X
136.14 Speed set value unlimited DINT 0x80000000 0x7FFFFFFF 0 Inc/ms 1:1 X
136.15 Output speed set value 32-bit DINT 0x80000000 0x7FFFFFFF 0 Inc/ms 1:1 X
137.1 Number of pulses UDINT 0 524288 1024 1:1 X
137.2 Number of revolutions UINT 0 0xFFFF 1 1:1 X
137.3 Encoder data selection UINT 0 0xFFFF 4 1:1 X
137.4 Notch position offset UINT 0 0xFFFF 0 1:1
137.5 M0-Offset angle UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
137.6 M0-Offset revolution UDINT 0 0xFFFFFFFF 0 1:1 X
137.7 M0-Sector position initiator DINT -2147483648 2147483647 0 1:1
137.8 Encoder operation time UDINT 0 0xFFFFFFFF 0 1:1
137.9 Time first commissioning UDINT 0 0xFFFFFFFF 0 1:1
137.10 Time last refresh UDINT 0 0xFFFFFFFF 0 1:1
137.20 Type name STRING 1:1 X
137.21 Serial number STRING 1:1 X
137.22 Firmware version STRING 1:1 X
137.23 Firmware date STRING 1:1 X
137.24 Eprom capacity UINT 0 0xFFFF 0 Byte 1:1 X
137.25 Data storage capacity UINT 0 0xFFFF 0 Byte 1:1 X
137.26 Defined fields UINT 0 128 0 1:1 X
137.27 Datafield status UINT 0 0xFFFF 0 1:1 X
137.28 Digital resolution UINT 0 65535 0 Bit 1:1 X
137.29 Position format UINT 0 65535 0 Bit 1:1 X
137.30 Instruction set UINT 0 0xFFFF 0 1:1 X
137.31 Resolution of revolutions UINT 0 65535 0 Bit 1:1 X
137.32 Angle resolution UINT 0 65535 0 Bit 1:1 X
137.33 Signal length UDINT 0 4294967595 0 nm 1:1 X
137.34 Measure step UDINT 0 0xFFFFFFFF 0 nm 1:1 X
137.36 Alarm mask UINT 0 0xFFFF 0 1:1 X
137.37 Alarm buffer UINT 0 0xFFFF 0 1:1 X
137.38 Warning mask UINT 0 0xFFFF 0 1:1 X
137.39 Warning buffer UINT 0 0xFFFF 0 1:1 X
137.42 Parameter of OEM 1, 2 UINT 0 0xFFFF 0 1:1 X
137.43 Parameter of OEM 3, 4 UINT 0 0xFFFF 0 1:1 X
