Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
795
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
138.1 Mode of Iq limit UINT 0 0xffff 0 1:1 X
138.2 Iq limit motor/TD1 FLOAT 0 100 100 % 1:1 X X
138.3 Iq limit generator/TD2 FLOAT 0 100 100 % 1:1 X X
138.4 Iq limit quadrant hysteresis FLOAT 0 100 5 % 1:1 X
138.5 Motor quadrant UINT 0 4 0 1:1 X
138.6 Iq upper limit FLOAT 0 10000 1.5 A 1:1 X
138.7 Iq lower limit FLOAT -10000 0 -1.5 A 1:1 X
138.8 Bitmask of external drive cur-
rent limit
UINT 0 0xFF 0 Bit 1:1 X
138.9 External limiting max. drive
current
FLOAT 0 10000 10000 A 1:1 X
138.10 External limiting max field
current amplitude
FLOAT 0 10000 10000 A 1:1 X
138.11 Iq set value before notch fil-
ter
FLOAT -10000 10000 0 A 1:1 X
138.12 Center frequency Iq set value
notch filter
FLOAT 0 8000 0 Hz 1:1 X
138.13 Bandwidth Iq set value notch
filter
FLOAT 0 4000 50 Hz 1:1 X
138.14 Iq limit bipolar cyclic UINT 0 16384 16384 % 4000
hex
:
100%
X
138.15 Iq limit bipolar FLOAT 0 100 100 % 1:1 X
138.16 Speed threshold for break-
down torque limit
FLOAT 0 1e9 0 U/min 1:1 X
138.17 Factor for breakdown torque FLOAT 0 1.41 0.9 1:1 X
138.18 Iq limit breakdown torque FLOAT 0 1e9 0 A 1:1 X
138.20 Max. torque actual value UDINT 0 0xFFFFFFFF 0 Nm 1000:1 X
138.21 Torque display DINT 0x80000000 0x7FFFFFFF 0 Nm 1000:1 X
138.22 Torque limit symmetric UDINT 0 2147483647 2147483647 Nm 1000:1 X
138.23 Kt correction factor FLOAT 0 100 1 1:1 X
138.24 Indication threshold torque UDINT 0 2147483647 2147483647 Nm 1000:1 X X
138.25 Status current limitation UDINT 0 0xFFFFFFFF 0 1:1 X
138.26 Limitation max current of
IPMSM
FLOAT 0 1e9 0 A 1:1 X
138.28 Hysteresis for Iq limit flag FLOAT 0 50 2 % 1:1 X
138.29 Time constant torque display FLOAT 0 1000 3 ms 1:1 X
139.1 Password UINT 0 0xFFFF 0 1:1
139.2 Baudrate UDINT 9600 921600 38400 1:1
139.25 Switch-on time UDINT 0 0xFFFFFFFF 0 s 1:1 X
139.26 Shutdown delay UDINT 0 0xFFFFFFFF 0 ms 1:1 X X
140.1 Mode WORD 0 0xFFFF 0 1:1 X
140.2 Status WORD 0 0xFFFF 0 1:1 X
142.1 Field weakening mode UINT 0 0xFFFF 0 1:1 X
142.2 Field weakening faktor FLOAT 0 1 1 1:1 X
