INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 4-63
Chapter 4 Frame and Carriage Assembly
Loading Optional Top Wheel Whisper Wheel®
Removing the Hub
4) Loosen the setscrews on the bearings of both arms as shown below.
5) Remove the Compression Cap fasteners and push it all the way toward the bearing on
both arms as shown below.
6) Loosen the Trans Torque on both arms as shown below.
To Next Page
