BONFIGLIOLI Agile User Manual

Parameter descriptions
Operation mode 531, 532, 533, 554
Function
7 - Ixt warning
The Warning limit short-term Ixt 405 or Warning Limit
Long-Term Ixt 406 is reached.
8 - Warning Heat Sink Temperature
Max. heat sink temperature T
K
minus the Warning limit
heat sink temp. 407 reached.
9 - Warning Inside Temperature
Maximum inside temperature T
K
minus the Warning
limit inside temp. 408 reached.
10 - Warning Motor Temperature
Warning according to configured Operation mode motor
temp. 570 and Max. motor winding temp. 617.
11 - Warning, General
The message is displayed via parameter
Warnings 269
.
12 - Warning Overtemperature
The selected limit values Warning limit heat sink temp.
407, Warning limit inside temp. 408 or the maximum
motor temperature have been exceeded.
13 - Mains Failure
Failure of the mains voltage and power regulation ac-
tive according to Operation Mode 670 for the voltage
controller.
14 - Warning Motor Protect. Switch
Parameterized Operation Mode 571 for the motor cir-
cuit breaker triggered.
15 - Warning Current Limitation
A controller or the Operation Mode 573 of the intelli-
gent current limits limit the output current. See chapter
7.6.5.6 "Current limitation".
16 -
Conroller Current Limit. Long Term
Ixt
The overload reserve for 60 s has been used up and
the output current is being limited. See chapter 7.6.5.6
"Current limitation".
17 -
Conroller Current Limit. Short Term
Ixt
The overload reserve for 1 s has been used up and the
output current is being limited. See chapter 7.6.5.6
"Current limitation".
18 - Controller Current Limit. Tc
Max. heat sink temperature T
K
reached, intelligent cur-
rent limits of Operation Mode 573 active. See chapter
7.6.5.6 "Current limitation".
19 - Controller Current Limit. Motor Temp.
Maximum motor temperature reached, intelligent cur-
rent limits of Operation Mode 573 active. See chapter
7.6.5.6 "Current limitation".
22 -
Warning V-Belt
Warning of
Operation mode
581 of V-belt monitoring
25 - Warning Mask
Message of the configurable parameter Create warning
mask 536. See chapter 7.6.5.8 "Warning mask".
26 - Warning, Application
A warning application is signaled. Display of the actual
value is effected via parameter Application Warnings
273. See chapter 7.6.5.9 "Warning mask, application".
27 - Warning Mask, Application
Message of the configurable parameter Create warning
mask application 626.
28 - Warning, gen + Warning, Application A warning or warning application is signaled.
29 -
Warn. Mask, gen + Warn. Mask,
Appl.
Message of configurable parameters Create warning
mask 536 and Create Warning Mask Application 626.
30 - Flux-Forming finished
Magnetic field has been impressed. See chapter 7.6.5.4
"Flux forming finished".
31 - Handshake Traverse Function
Signal of the traverse function. See chapter 7.10.8
“Traverse function”
41 - Brake release
Activation of a brake unit depending on the Operation
Mode 620 for the starting behavior, Operation Mode
630 for the stopping behavior or the configured brake
control system. See chapter 7.6.5.5 "Release brake".
43 - External fan
The Switch-on temperature 39 has been reached. An
external fan can be switched on by the signal. See
chapter 7.6.5.7 "External fan".
50 - Warning service fan
The time remaining until service has expired. See chap-
ter 10.3.2 “Fan”.
