Parameter descriptions
On the output, the logic signal 927 - "Output MUX" for the inputs of the TxPDO process data of the
system bus or for PZDx-IN process data of the Profibus can be used.
1252 Mux Inputs 7 -
Off
1250 Mux Input Index (write)
1251 Mux Input index (read)
The parameters Mux Input Index (write) 1250 and Mux Input Index (read) 1251 for the input signals
of the multiplexer enable parameterization via the operator panel or the application VTable in VPlus.
Mux Input Index (write)
1)
1251 Mux Input Index (read) 0 33 1
non-volatile (fixed parameterization):
Setting "0" for Mux Input Index (write) 1250 changes all data in EEPROM and RAM.
In the case of non-
volatile storage (0...16), the changed values are still available when
power supply is switched on again.
In the case of volatile storage (17…33), the
data is only stored in RAM. If the unit is
switched off, this data is lost and the data required are loaded from EEPROM.
Demultiplexer:
1253 DeMux Input
The demultiplexer features an input
DeMux Input 1253 whose signal can be for the process data
RxPDO of the system bus or OUT-PZDx of Profibus.
On the output of the demultiplexer, the logic signals “910 - Output DeMux Bit 0” to “925 - Output
DeMux Bit15” are available, e.g. for control of PLC-functions.
Operation modes for DeMux input 1253
Remote control word , remote state word
900 -
Controller status
927 -
Output MUX
910 … 925 -
Output DeMux Bit 0 ... output DeMux Bit 15
206
Operating Instructions
Agile
06/2013 Control inputs and outputs
