Parameter descriptions
478 Actual Percentage Source, PID real value input
The analog input or the repetition frequency input to which the PID real value is applied can be se-
lected via parameter
Actual Percentage Source 478. The actual value can also be transmitted via a
bus system.
Actual Percentage Source 478
Function
1 - Analog Input MFI1A
Analog signal at multifunction input 1 (terminal X12.3). Factory
setting. Via parameter Operation mode MFI1 452, the input
must be set up as an analog input (voltage or current). See
chapter 7.6.1 "Multifunction input MFI1".
2 - Analog Input MFI2A
Analog signal at multifunction input 2 (terminal X12.4). Via pa-
rameter Operation mode MFI2 562, the input must be set up
as an analog input (voltage or current). See chapter
7.6.2
"Multifunction input MFI2".
32 - Rep. Percentage Input
Percentage signal at digital input IN2D. Evaluation can be se-
lected via parameter Operation mode IN2D 496. See chapter
7.6.7.2 "Repetition frequency input".
40 - Actual Percentage RAM
Value of parameter Actual Percentage RAM 529. Actual Per-
centage RAM 529 can be set via Fieldbus, but is not visible in
VPlus or the keypad.
704 -
RxPDO1 Word 1
Process data from system bus. Refer to system bus instructions.
705 -
RxPDO1 Word 2
Process data from system bus. Refer to system bus instructions.
2521 - PLC-Output Percentage 1
Output value of a PLC-function. Percentage output 1 of the
table function is the PID real value source. See application
manual "PLC".
2522 - PLC-Output Percentage 2
Output value of a PLC-function. Percentage output 2 of the
table function is the PID real value source. See application
manual "PLC".
223
Control functions 06/2013 Operating Instructions
Agile
