7
The Step 3: Paper Source Settings dialog box is dis-
played. Select the paper source where the custom pa-
per is loaded and then click the OK button.
8
The Step 4: Paper feed adjustment dialog box is
displayed. Click the Execute button to execute paper
feed adjustment.
The adjustment pattern is printed, and the paper feed
is automatically adjusted based on the printing result.
Once the paper feed adjustment is complete, click
the Next button.
Important
• Check that there is no paper left on the ejection guide.
• If Paper Feed Adjustment is not executed, horizontal stripes with different color tones may appear in the prin-
ted material. Paper feed adjustment does not need to be executed more than once. Execute paper feed adjust-
ment only once each time you add a custom paper.
9
The Roll Paper Settings dialog box is displayed.
Note
• If a paper source other than Roll Paper is selected in the Step 3: Paper Source Settings dialog box, this
screen is not displayed.
Configure the following settings as necessary, and then click the Next button.
Setting Details
Automatic Cutting Settings Configures the method for cutting roll paper when it is ejected after printing.
•
Automatic Cut:Roll paper is automatically cut by the cutter unit.
•
Eject Cut:When the Cut key is pressed on the printer control panel, the roll paper is cut
by the cutter unit. Select this if you do not want the printed material to drop immediately
after printing, such as to wait for the ink to dry.
iPF6400S
Add Custom Paper
User's Guide
Handling and Use of Paper Media Configuration Tool (Mac OS)
557
To Next Page
