Adjustment for high-precision printing
Adjustment for high-precision printing
Enhancing Printing Quality
Enhancing Printing Quality
With some types of paper and under some conditions, adjusting the printer as follows with the paper to be used
can enhance printing quality when printing fine lines/text or photos.
Two adjustment options are available: standard adjustment (with the Printhead height set to Automatic ) and sup-
plemental adjustment (used if standard adjustment is not effective).
Important
• Ideal temperature and humidity during adjustment and for printing in general when the Printhead height is set to Auto-
matic are 20–30ºC and 30–60%. Under other environmental conditions, adjustment may not enhance printing quality.
Standard Adjustment
Perform standard adjustment with the Printhead height set to Automatic.
1
Load paper in the printer.
•
Loading Rolls on the Roll Holder ➔ P.471
•
Loading Rolls in the Printer ➔ P.473
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab ( ).
Note
• Auto(Expansion) may be unavailable in some cases, even if it is displayed in the menu.
If so, execute Auto(Advanced) once.
• If the Tab Selection screen is not displayed, press the Menu button.
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
Press ▲ or ▼ to select Head Posi. Adj., and then press the OK button.
6
Press ▲ or ▼ to select Auto(Expansion), and then press the OK button.
A test pattern is printed for adjustment. It takes about 15 minutes.
Note
• If standard adjustment does not enhance printing quality, next try supplemental adjustment, which may be helpful.
Supplemental Adjustment
Perform supplemental adjustment with the Printhead height set to Super Low.
Important
• Printing with Head Height set to Super Low may enhance printing quality, but it may also cause paper to rub against or
become caught on the Printhead, which may cause paper jams or soiling on printed documents.
Note
• We recommend that additional adjustment be executed using paper matching the following criteria.
Type: Glossy or semi-glossy photo paper, or proofing paper (in either case, roll paper only)
Thickness/weight: 300 μm or less, or 300 g/m² or less
Width: 420.0 mm (16.54 in.) or more
1
Set Head Height to Super Low. (See "Troubleshooting Paper Abrasion and Blurry Images.") ➔ P.712
Note
• If Super Low is not available, select Lowest.
Enhancing Printing Quality
iPF6400S
User's Guide
Adjustments for Better Print Quality Adjustment for high-precision printing
706
