83. Install a new transfer gear (underdrive compounder side) nut and tighten to 271 N.m (200 ft. lbs.).
84. Use Staking Tool 9721 and stake the new nut.
Fig. 171: Differential Out & In
Courtesy of CHRYSLER LLC
85. Install the differential, bearing cups, shim and oil slinger into case.
Fig. 172: Differential Cover
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
