Chrysler 62TE - Page 108

Fig. 169: Output Gear Bearing Cone
Courtesy of CHRYSLER LLC
81. Install the transfer gear (underdrive compounder side) cone using Installer 6756 (3).
Fig. 170: Holder 9739
Courtesy of CHRYSLER LLC
82. Install Holder 9739 (1) onto the transfer gear (underdrive compounder side) (2).
1 - ARBOR PRESS RAM
2 - HANDLE C-4171
3 - INSTALLER 5052
4 - OUTPUT GEAR
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
