Chrysler 62TE - Page 112

Fi
g
. 176: Transfer Gear Cover
Courtesy of CHRYSLER LLC
93. Install the transfer gear cover (1), use a bead of MOPAR® ATF RTV (MS-GF41).
94. Install transfer gear cover-to-case bolts (2) and tighten to 12 N.m (105 in. lbs.).
Fig. 177: Park Pawl Tube
Courtesy of CHRYSLER LLC
95. Install the park pawl tube (1) into case (2) makin
g
sure
g
uide pin ali
g
ns with hole in case.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
