Chrysler 62TE - Page 113

Fig. 178: Park Pawl Tube Snap Ring
Courtesy of CHRYSLER LLC
96. Install the snap ring (1) for the park pawl tube.
Fig. 179: Park Pawl
Courtesy of CHRYSLER LLC
97. Install the park pawl (1) and the park pawl sprin
g
(2).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
