Fig. 182: Set Screw At Park Pawl Shaft
Courtesy of CHRYSLER LLC
100. Install the set screw (1) for the park pawl shaft and tighten to 1 N.m (10 in. lbs.).
101. Install the manual lever, TRS and seal. See Transmission and Transfer Case/Automatic -
62TE/SENSOR, Transmission Range - Installation.
Fig. 183: Accumulators
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:08 PM Page 115 © 2006 Mitchell Repair Information Company, LLC.
