110. Install the valve body oil pan, use a bead of MOPAR® ATF RTV (MS-GF41).
111. Install the valve body oil pan bolts and tighten to 6 N.m (53 in. lbs.).
Fig. 189: Pressure Tap Plug
Courtesy of CHRYSLER LLC
112. Install the pressure tap plug (2) at valve body pan and tighten to 9 N.m (45 in. lbs.).
Fig. 190: Oil Filter Seal At Case
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
