Chrysler 62TE - Page 118

Fig. 187: Connector At Transmission
Courtesy of CHRYSLER LLC
107. Install the detent spring (2).
108. Install the bolt (3) holding the detent spring and tighten to 7 N.m (50 in. lbs.).
109. Install the electrical connector (1) at the range sensor (4).
Fig. 188: Valve Body Pan
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
