. 199: Torque Converter Bolts
Courtesy of CHRYSLER LLC
9. On 3.8L engines Install transaxle into position
10. Install the two lower transaxle-to-engine bolts and torque to 60 N.m (44 ft. lbs.).
11. Install torque converter-to-driveplate bolts (1) and tighten to 88 N.m (65 ft. lbs.).
Fig. 200: Structural Collar
Courtesy of CHRYSLER LLC
12. Install the bolts holding structural collar to the oil pan (1) and transmission (2) tighten to 75 N.m (55 ft.
lbs.). Refer to Engine/Engine Block/COVER, Structural Dust
- Installation .
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
