Fig. 198: Exhaust Bracket Bolts
Courtesy of CHRYSLER LLC
5. Install bolts (2) to stand off bracket (4) and tighten to 95 N.m (70 ft. lbs.).
6. Install the remaining transaxle-to-engine lower bolts and torque to 60 N.m (44 ft. lbs.).
7. Install the cross under exhaust pipe (If equipped). Refer to Exhaust System/PIPE, Exhaust Crossunder
- Installation .
8. Install bolts (3) to exhaust bracket.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
