Fig. 325: Input Clutch Hub, Retainer & OD/Reverse Piston
Courtesy of CHRYSLER LLC
7. Refer to the illustration as necessar
y
when performin
g
the followin
g
steps.
1 - SNAP RING (INPUT SHAFT)
2 - SNAP RING
3 - CLUTCH RETAINER
4 - SEAL, OUTER
5 - SEAL, INNER
6 - OD/REVERSE PISTON
7 - SEAL, INPUT SHAFT
8 - SHAFT, INPUT
9 - HUB
10 - SEAL
11 - SNAP RING
12 - BELLEVILLE SPRING
