Fig. 401: Direct Clutch Measurement
Courtesy of CHRYSLER LLC
34. Using a Dial Indicator and air pressure measure the direct clutch clearance, the clearance should be 0.95 -
1.41 (0.037 - 0.056 in). Install desired selectable reaction plate to achieve correct clearance.
Fig. 402: Clip At Transfer Shaft
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:10 PM Page 239 © 2006 Mitchell Repair Information Company, LLC.
