40. Install the thrust washer (7) on the front side of the annulus gear.
41. Install the snap ring (6) that holds the annulus gear.
42. Install the planetary carrier (5).
43. Install the snap ring (4) holding the planetary carrier.
Fig. 404: Helical Shim
Courtesy of CHRYSLER LLC
44. Install the helical shim (1).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
