. 410: Cable At Bulkhead
Courtesy of CHRYSLER LLC
1. Install the gearshift cable (2) through the bulkhead (1) from the passenger compartment.
2. Seat the rubber grommet onto the bulkhead. Make sure the grommet is fully engage to the bulkhead.
Fig. 411: Shift Cable From/To Manual Lever
Courtesy of CHRYSLER LLC
3. Connect the gearshift cable (1) to the bracket.
4. Connect the
earshift cable to the transaxle manual valve lever (2).
NOTE: Make sure the rubber grommet in the bulkhead is fully seated to prevent water
leaking into the passenger compartment.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:10 PM Page 246 © 2006 Mitchell Repair Information Company, LLC.
