Fig. 412: Gearshift Cable
Courtesy of CHRYSLER LLC
5. Install the gearshift cable (1) to the shifter. Make sure the lock tab (2) on the gearshift cable is fully
seated.
6. Install the knee blocker (2). Refer to Body/Instrument Panel/KNEEBLOCKER - Removal .
7. Install the battery tray. Refer to Electrical - Engine Systems/Battery System/TRAY, Battery -
Installation .
8. Install the battery. Refer to Electrical - Engine Systems/Battery System/BATTERY - Installation .
ADJUSTMENTS
ADJUSTMENTS
ADJUSTMENT
1. Park the vehicle on level ground and set the parking brake.
2. Place the gearshift lever in gated park (P) and remove ignition key.
3. Loosen the cable adjustment screw at the transaxle manual valve lever.
4. Pull the gearshift lever fully forward to the park detent position.
5. Release the park brake, then rock the vehicle to assure it is in park. Reset the park brake.
6. Tighten the cable adjustment screw to 8 N.m (70 in. lbs.). Gearshift cable should now be properly
ad
usted.
NOTE: Make sure the lock tab on the gearshift cable is fully seated after the
gearshift cable is installed to the shifter housing.
