Chrysler 62TE - Page 263

Courtes
y
of CHRYSLER LLC
6. Install side gear thrust washer (1) to case.
Fig. 436: Differential Support
Courtesy of CHRYSLER LLC
7. Install differential support (1) into position, while ali
g
nin
g
throu
g
h-holes.
1 - SIDE GEAR THRUST WASHER
1 - DIFFERENTIAL SUPPORT
2 - DIFFERENTIAL CASE
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
