Fig. 437: Ring Gear
Courtesy of CHRYSLER LLC
8. Install differential ring gear (2) to case (1).
Fig. 438: Ring Gear
-To-Case Bolts
Courtesy of CHRYSLER LLC
1 - DIFFERENTIAL CASE
2 - RING GEAR
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
