will be encountered. Mark this location (driveplate and converter) with paint for assembly reference.
Fig. 35: Torque Converter Bolts
Courtesy of CHRYSLER LLC
44. Remove the six transaxle-to-engine lower bolts.
45. Lower transaxle from en
ine compartment.
NOTE: The bolts on each side of the inspection opening were removed with the
exhaust bracket.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:07 PM Page 30 © 2006 Mitchell Repair Information Company, LLC.
